Mini Electric Trolley

Mini Electric Trolley

Established in the year 1987, we, Max Industries are the prominent manufacturer, supplier and exporter of Mini Electric Trolley. Made in line with international quality standards, these electric trolleys are suitable for double girder operation. We ensure that a damage free and flawless quality Mini Electric Trolley reaches at the clients' end. Perfect finish, robust construction and high strength are the distinguished features of these electric trolleys. Moreover, we are committed to offer these trolleys to clients without any delay.

Further Details:

The Trolleys manufactured here are of best quality with precision finishing and checked in various conditions for full safety of the product.

Available range:

Easily interchangeable & available Spares.

Guarantee: One Year from date of purchase on F.O.R. Kapadwanj basis, for free repair, replacement of any part proved diffective in material or workmanship.

Monorail Electric Traveling Trolley

Available upto 15.0 Ton Capacity.

Designed for moving the trolley by pressing push button to move the Lifted Load along the I-Beam axis Robust Rigid Construction, yet easy to assemble & dismantle.

Driven by Special design, Sq. Cage, Face mounted, 3 Phase, Class F, 960 RPM, Motor.

Gears: Alloy Steel Material, precise machined, gear hobbed & case hardened duly annealed. Spur / Helical combination to provide strength & smooth operation. Gears shall be lubricated with semi-liquid grease instead of oil, which is less likely to leak, eliminates oil level checks and clings to the gears even after long idle periods.

Trolley wheels are machined for accuracy in its taper & surface on CNC Machines (upto 3T) & running on roller/ ball bearings to minimize the frictional load giving minimum effort for the operation.

Evenly distributed Load on four wheels.

Gear Wheels: Precise machined, gear hobbed.

Adjustable in width to suit to the I-Beam flange width requirements.

Control Panel Unit: Totally enclosed to protect from Weather, giving output at 24 Volts to the Operational Control Station (Push Button Station).

Operational Control Station: Suspended from Hoist with a Cable & supporting Wire rope with two push buttons extendable to four / six push button station.

Operated with 24 Volts.

Interchangeable Spares.

Special Trolleys with A.C. Electromagnetic Brake, Limit Switches can be supplied at an extra cost.

Trolleys with higher capacity or suitable for double girder operation can be designed & supplied on request.
