Colloid Mill (R & D) Mini

Model	KSD-CM-(MINI)
Output*	1 to 5 Kgs./ Shift.
Particle size reduction *	5 to 10 Microns.
Hopper capacity	5 Liters.
Motor	1 Hp / 2850 RPM / 440 V. / 3 Ph. / 50 Hz.
Height	600 mm
Floor space	400 x 510 mm
Net weight (Approx.)	80 Kgs.
Gross weight(Approx.)	150 Kgs.
Machine Dimensions	400 (L) x 510 (B) x 600 (H)
Case Dimension	550 (L) x 650 (B) x 700 (H)

All contact parts are made out of S. S. 304 (S.S.316 on demand at extra charges).

Coupling provided between motor shaft and rotor shaft for ease in maintenance.

Three oil seals between the motor and the processing chamber to prevent liquid going in the motor winding, resulting in the burning of the motor.

Modified design of semi concave teeth in rotor and stator reduced motor HP and gives better performance in size reduction without damaging the product.

Extended bearing housing specially designed to facilitate fine adjustments of bearing clearances or backlash to avoid metal to metal contact of rotor and stator. This unique design provides smooth and consistence all round performance and long life of rotor and stator.

Leak proof neoprene sealing device.

Three-way cock for draining and recirculation of liquids provided as standard. Extra discharge spout provided as a standard for viscous products.

DOL starter with overload relay for protection against single phasing and low voltages.

Contact parts can be easily dismantled for cleaning.

Special design facilitates adjustment of grinding gap by an exterior screw by means of handle even during operation.

Flameproof motor and flameproof rotary switch can be provided on request at extra cost.
