Drill Machine Single Double Model
Drill Machine Single Double Model
Technical Specifications
|
Drilling Cap. in Steel in Inches |
1 |
1-1/4 |
1-1/2 |
2 |
2-1/2 |
3 |
|
Dia of column in Inches |
5-1/4 |
6-1/4 |
9-1/4 |
10-1/2 |
12 |
14 |
|
Max. Distance from spindle to column in inches |
25 |
30 |
36 |
40 |
44 |
48 |
|
Min. distance from spindle to base plate in Inches |
10 |
12 |
13 |
16 |
18 |
18 |
|
Max. distance from spindle to base plate in Inches |
33 |
42 |
50 |
52 |
52 |
52 |
|
Total No. of Spindle speeds |
4x2 |
4x2 |
3x2 |
3x2 |
3x2 |
3x2 |
|
Range of spindle speeds R.P.M. |
80-700 |
80-700 |
40-700 |
20-500 |
20-500 |
20-500 |
|
Travel of Spindle in Inches |
6 |
8 |
9 |
9 |
12 |
14 |
|
Spindle Morse Taper no |
M. T. 4 |
M. T. 4 |
M. T. 4 |
M. T. 5 |
M. T. 5 |
M. T. 6 |
|
Horizontal adjustment of the arminches |
14 |
17 |
24 |
24 |
26 |
28 |
|
Arm tilt to any angle up to |
90° |
90° |
90° |
90° |
90° |
90° |
|
Floor space required |
22x34 |
24x41 |
30x54 |
33x58 |
35x62 |
36x66 |
|
Power recommended (H.P.) |
1 |
1.5 |
3 |
5 |
5 |
7.5 |
